Descripción
Diseño de cable oculto, 50 metros Longitud total máxima de los accesorios en cadena a 220 V sin repotenciación.
| 6Pixel/M T42D RGB LED Linear Light Technical Specification | |||
| LED Type | SMD5050 RGB 3in1 | Waterproof Treatment | Full Silicone potting |
| Beam | 140° | Control | DMX(18Channels)/SPI |
| Dimension | 1000*24*24 mm | Front Face | Clear Polycarbonate |
| Q'ty of lamps | 42/mtr | End Cap | ABS |
| Certification | CE/ROHS/FCC | Weight | 260g/m |
| Grayscale | 8 bit (256) |
Maximum Chain Length |
50 meters |
| Power consumption | 14 W/M | Ingress Protection | IP67 |
| Drive Volgtage | 24 V/DC | IC Type | TM1914 or UCS512 |
| Power Management | Low voltage protection | Design Life | ≥ 50000 hours |
| Housing | Extrusion Aluminum | Controller | MR-502/Madrix |
